Ulvac LR Series - Performance Curve

21
0
200
400
600
800
1000
1200
1400
1600
1800
2000
1.0E-01 1.0E+00 1.0E+01 1.0E+02 1.0E+03 1.0E+04 1.0E+05
LR/HR300 Frec.50
LR/HR300 Frec.60
LR/HR600 Frec.50
LR/HR600 Frec.60
LR/HR1200 Frec.50
LR/HR1200 Frec.60
LR/HR1800 Frec.50
LR/HR1800 Frec.60
1.6 Performance Curve
Pumping speed curve
(Primary pump units)
Pumping speed (m
3
/hr)
Inlet pressure (Pa)
Inlet pressure (Pa)
Pumping speed curve
(Booster pump units)
Pumping speed (m
3
/hr)
