UT25CL User Manual
36
or lights off.
2. UT25CL-T is in power-
on state with batteries
installed: the ELV LED lights off
3. UT25CL-T is in power-
off state with batteries
installed: If external voltage applied is >25V, the ELV
LED emits weak light and its brightness increases as
voltage rises (light up constantly), otherwise, the ELV
LED emits weak light or lights off.
Certification
CE Certified
EMC: EN IEC 61326-1
LVD: EN 61010-1
EN IEC 61010-2-033
Rohs
10.2 Receiver Specifications
Characteristics
UT25CL-R
Working frequency
33kHz
Locating depth
Related to the medium and the method used
Tracking mode for single pole
About 0~2.5 m (Use separate loop wire for 2.5 m)
Tracking mode for dual poles
About 0~0.5 m
Grid voltage identification About 0~0.4 m
NCV
Voltage identification range: 80~1000V, 50Hz/60Hz
(Approach the measured cable)
Display
Segmented LCD (TN translucent)
Battery 6 × 1.5V AAA (LR03)
Power consumption
About 30mA (Excluding backlight and flashlight)
About 65mA (Excluding backlight)
Maximum 95mA (including backlight)
Operating temperature 0~40℃; Max. 80%RH (Non-condensing)
Storage temperature -20~60℃; Max. 80%RH (Non-condensing)
Operating altitude
≤
2000m
External dimensions
226*68*38mm
Button life
10000 times
Weight (excluding batteries)
About 287g
Weight (including batteries)
About 354g
I
ndication for running out of
power (For transmitter)
Supported
Backlight
Supported
Flashlight
Supported
CODE (code value)
0, 1, 2, 3, 4, 5, 6 and 7
Levels of signal strength of
Level 1, Level 2, and Level 3
