BRAKING SYSTEM “ ABS “
Principle:
The revolving speed of the turntable is measured during the phase just before its stop. According to the
speed measured, it will be applied automatically a corresponding delay to the braking phase. If the
turntable is fairly free (low friction, none running infusion), the speed is high and so the braking is
immediate. If the turntable revolves with a friction applied (during the infusion of one piston for
example), the speed is lower and so we apply a corresponding delay (a few milliseconds) to the
braking phase, so that the turntable does not stop too early.
Possibility to change the factory setting:
If the factory setting is not correct and you see that the turntable does not stop at the right position, you
can act on this setting by changing the value of the parameter ABS located in a new menu called
TURNTABLE SETTING.
The parameter ABS is usually factory adjusted: ABS = 00
- If in spite of the new electronic braking system, you see the turntable stops over the correct
position, you can reduce gradually the ABS value to (-100) maximum. If the turntable stops before
the correct position, you can increase in the same way the ABS value to (+100) till the positioning
is correct.
Note that the value (-100) neutralises the braking automatic control and apply an instantaneous
braking without taking into account the speed of the turntable, as on the previous software versions.
How to change the value of ABS with the technical card only:
MENU
Menu selection / Display
+/ -
TURNTABLE SETTING
PRO 3 sec
ABS = 00
PRO
ABS= "00 " blinking
+/-
To change the value
PRO
To valid
MENU
To escape
WARNING:
- In order to the ABS system runs correctly, it is compulsory that the Tango be fitted with the new
larger (35 mm) turntable stop plate (FR2032). If you don’t have the larger turntable stop plates the
machine can work correctly with the smaller ones (but without the ABS advantage) by
programming ABS= - 100.
- The data cards (green ones) delivered with the new versions including ABS system, are not
compatible with the previous versions and reciprocally.
