Unic Tango User Manual

14/06/02 PA
INTERFACE DIAGRAM
TO CONNECT
INFORMATIC SYSTEM
CREDIT / DEBIT AND DEBIT/ CREDIT
TANGO
TRANSMISSIONS
PARAMETERS:
-1200 bit / sec.
- Parity EVEN
- 8 bit of datas
- 1 bit of stop
INTERFACE I/O Réf: 45335
CN5
RL8
RL7
RL6
RL5 RL4 RL3 RL1
RL2
RL16
RL15
RL14
RL13
RL12 RL11 RL9
RL10
RL24
RL23
RL22
RL21 RL20 RL19 RL17RL18
RL32
RL31
RL30
RL29
RL28 RL27
RL25
RL26
CN8
1
40
BADGE
RL33
RL1
RL2
RL32
RL33
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
serie transmission led
interface alimentation led
1
40
CN8
Ground 1
TXD 2
RXD 3
Alim. + 4
Réf: FR8047
Réf: 45325
3
4
2
1
CN5
CN7
JUMP JP3
N°1
N°40
Connect to the ground of
the mother card
Circuit attached to
the electronic card
of the Tango
Nota : the coffee machine is only usable when the badge contact is closed.
To simulate the presence of the badge it is possible to jump on the points 33 and 35 of the connector CN7 of
the interface I/O. To allow the coffee machine running without interface, we must jump the points 2 and 3 of
the cable, ref. 8047.
Important : the coffee machine must be equipped in V119W3H or from the V143.
AFTER CONTROL
DISCONNECT
CN7 OF THE LED
CARD AND CONNECT CABLE
DV8132
RL8
RL7
RL6
RL5RL4
RL3
RL1 RL2
RL16
RL15
RL14
RL13
RL12RL11
RL9
RL10
RL24
RL23
RL22
RL21RL20RL19RL17 RL18
RL32
RL31
RL30
RL29
RL28RL27
RL25
RL26
CIRCUIT CONTROLING THE IMPULSIONS
LED CARD réf: 45334
BADGE JUMP
For a machine from V143 version : you should select MENU > COIN DEVICE > CD or DC – Configure the
machine in Self mode – place or remove the jump JP3. See below.
For a machine with V119W3H only the mode credit/debit is possible and the jump JP3 is not used.
ATTENTION : In CD mode the beverages E and F and from Lx2 are not available (see separate list for details) -
the MANUAL and CONTINU keys are not useable – The paramater repetition of cycle should be at 1.
JUMP JP3 : to configure mode Crédit / Débit (CD) or Débit / Crédit (DC).
*
For DC, place the jump JP3.
* For CD, remove the jump JP3
.
08/09/05 RLR
08/02/08 AP
29/03/07 AP
I-17
