Unic Tango User Manual

To configurate the machine in self mode only:
a) Switch off the machine
b) Put the bridge on JP1 on the 2 low wedges
c) Put the bridge on CN7 on the top wedges (1-3)
To configurate the machine in coiners mode
d) Configurate the machine in self mode
e) Add the bridge on CN13 on the 2 left wedges (1-2)
