UNICORECOMM Unicore User Manual

Command and Log Reference
16
Num
ber
Device
Name
Device Description
1
COM1
COM1 serial port: port settings related to COM1, such as baud
rate, parity bit.
2
COM2
COM2 serial port: port settings related to COM2, such as baud
rate, parity bit.
3
COM3
COM3 serial port: port settings related to COM3, such as baud
rate, parity bit.
4
INS
INS configuration: enable/disable INS, INS installing angle
5
ANTENNA
Antenna feed switch configuration
6
PPS
PPS configuration: enable/disable PPS output, polarity, period
and pulse width.
7
EVENT
Event configuration: reserved.
8
UNDULATION
Geoid undulation configuration: input a specific undulation
value or use built-in geoid grid.
9
RTK
RTK configuration: RTK solution、maximum age of RTK data.
10
DGPS
DGPS configuration: maximum age of DGPS data.
4.1 Configure Antenna
This command is used to configure the power switch of antenna. The receiver is
connected to an active antenna, that is, the receiver will feed the antenna through the
RF cable. The receiver will feed the antenna through the RF cable by default.
Command Format:
CONFIG ANTENNA [parameter]
Abbreviated ASCII Syntax:
CONFIG ANTENNA POWERON
CONFIG ANTENNA POWEROFF
Table 4-2：Antenna Configuration
Command
Device
Field
ASCII Value
Parameters Description
CONFIG
ANTEN
NA
SWITCH
POWERON
Switch on the antenna feed
POWEROFF
Switch off the antenna feed
4.2 Configure Undulation
This command permits you to either enter a specific geoid undulation or use the
built-in grid value of geoid undulations.
Command Format:
CONFIG UNDULATION [Parameter]
