mode movingbase
Set the moving base station mode
mode rover
Set the default rover station mode (disable base station
mode)
rtcm1033 comx 10
rtcm1006 comx 10
rtcm1074 comx 1
rtcm1124 comx 1
rtcm1084 comx 1
rtcm1094 comx 1
Set base station to transfer RTCM messages to rover
receivers via the serial port comx.
The serial port can be assigned as com1、com2、com3.
NMEA0183 Messages Associated
gpgga comx 1
Set the GGA message output at rates 1Hz.
Message type and logging period support user selection.
The valid logging period are:1, 0.5, 0.2, 0.1, corresponding
to 1Hz、2Hz、5Hz、10Hz.
The optional message types are: GGA、GSV、GSA、
RMC、GST、VTG、ZDA、NTR.
gphdt comx 1
Set the HDT message output at rates 1Hz.
Vessel heading message types include HDT and TRA.
1.1. Base Station Configuration
For RTK reference station (fixed base station), the antenna is placed at a fixed
place, and won’t move.
The precise coordinates of the known point and the satellite information received
are sent to the rover station receiver (the undetermined point), the rover station
receiver also receives the base station information and the satellite observations, then,
performs RTK solution to achieve the centimeter level or millimeter level accuracy
positioning. Frequently commands used to configure the RTK base station are as
follows.
When the precise coordinate is known, input the following commands to the
receiver:
Table 1-2: Fixed Base Station Configuration
Number
Command
Description
1
mode base lat lon hgt
Set the known base station coordinate:
latitude、longitude、 ellipsoid height
2
rtcm1006 com2 10
Base station antenna coordinate (antenna height
included)
3
rtcm1033 com2 10
Receiver and antenna description
4
rtcm1074 com2 1
GPS system correction data
5
rtcm1124 com2 1
BDS system correction data
6
rtcm1084 com2 1
Glonass system correction data
7
rtcm1094 com2 1
Galileo system correction data
