Toner / Drum Cartridge Replacement Guide
Because the IColor 650 features cartridge remapping to achieve a white underprint or overprint, it is important that
you follow these rules when determining which color cartridge to order (pertains to both toner and drum units):
OVERPRINT Queue Configuration Supplies Replacement Guide
Typically used for reverse print applications such as garment decoration
White/Clear (check which cartridge is installed) (Back of Printer)
UNDERPRINT & CMYK Queue Configuration Supplies Replacement Guide
Typically used for right side reading application such as printing on dark or clear media
(check which cartridge is installed) (Front of Printer)
IMPORTANT NOTES:
1) When moving cartridges between overprint, underprint and CMYK configurations, the toner and drum units must
move as a set.
Never disengage or turn the blue lever of the toner unit during this process.
You cannot put the white toner cartridge into the cyan drum unit (or vice versa) as it will cause catastrophic
contamination, rendering the drum unit unusable.
2) Always power down your printer before moving cartridges to prevent electrostatic damage.
3) When switching cartridge configuration and also changing the white/black/clear cartridge, it should be done in
two separate steps. It is not suggested to do this all at the same time.
• First switch the configuration, then power on the printer.
• Once it comes to ready, power down and swap the black/white/clear cartridge and power on again.
• Failure to follow this procedure could result in a cartridge error.
4) The black, white, clear, gold or silver cartridges can never be installed together. Only one of these 5 cartridges can
be installed at any one time.
