7) Remove the tape (5) from the toner cartridge.
8) Insert a new toner cartridge (6) by aligning its left side indentation (7) with the protrusion (8) on the image drum
so the toner cartridge and image drum color label align. Then insert the right side gently into place.
9) While pressing the toner cartridge, turn the toner cartridge lock lever (blue) (3) backward until it aligns on the
mark, and lock the toner cartridge to the image drum.
• You will hear a click when it is locked in place.
Closing the cover without turning the toner cartridge lock lever (blue) may cause a malfunction. Make sure to turn
the cartridge lock lever until it lines up with the arrow in the far end.
10) Close the front cover (2).
11) Recycle your cartridge – request a return label from Uninet.
