3.6. Terminal information view
◆ [*] ◆[4]
In the main menu, press [4] to select “4.Terminal info” and the following screen
appears; where all the environmental settings are displayed:
Terminal ID=0001
Ver=10.51.00
Application
=Access
Language=ENG
Mode=SN
Press [0] to scroll up and down the screen.
Terminal ID Terminal ID
Version Terminal firmware version.
Application Terminal application mode (Access/T&A).
Language Language for text and voice of the LCD screen.
Mode Connection mode between terminal and network server.
Network type Network connection type (static IP/dynamic IP).
Mac Address Terminal Ethernet hardware address.
IP address Terminal IP address.
Gateway Terminal gateway address.
Subnet mask Terminal subnet mask address.
Server IP IP address of network server connected to the terminal.
Svr-port Port number of network server program.
Card Reader Card reader type.
Card Reader
Version
Card reader firmware version.
FP-Sensor Fingerprint sensor type.
1:1 Level Identification level for 1:1 authentication.
1:N Level Identification level for 1:N authentication.
Max User
Maximum user capacity to be able to be registered to a
terminal.
Max FP
Maximum fingerprint capacity that can be registered to a
terminal. For example, if there are 100 registered users and
two fingerprints per user are registered, it means a total of
200 fingerprints are registered.
All User
Number of current users registered to a terminal including
administrators.
All Admin Number of administrators registered to a terminal.
