- Password authentication
After inputting the user ID, and changing the authentication mode by pressing
the corresponding function key, input the password for authentication.
- Card authentication after the following settings are done: menu “6.Device”
settings “3.Card reader” <Card Reader> is set to [1] or over
Pressing the function key changes just the authentication mode. For card
authentication, press the corresponding function key and then place the card
close to the terminal.
4.1.2. [1:1] fingerprint authentication
▶ When auto sensing is running, input ‘0001’ if the user ID is ‘0001’ and then
place your finger close to the fingerprint sensor. The light on the fingerprint input
window turns on to detect the fingerprint and the authentication result is
displayed on the LCD window.
If the user ID is ‘0001’, input ‘0001’ and press the func▶ tion key. Voice
information such as, ‘please enter your fingerprint’ follows. When a fingerprint is
input, the authentication result is displayed on the LCD window.
== 00:00
0001
If the user ID is ‘0001’, input ‘1’ or ‘0001’ and press
the function key.
▼
== 00:00
Place your finger close to the input window when you
hear the voice message “Please enter your
fingerprint”. Do not remove your finger until you hear
a “ppig” buzzer sound.
▼
== 00:00
If authentication is successfully done, a success
message is displayed on the LCD together with a
voice message “You are authorised”. The door LED
turn on and door relay runs.
The default screen appears after 1~2 seconds. The
door LED turns off and door relay releases after the
door open setting time has elapsed.
※ Error message: The following error message appears together with a voice
message “Please try again”.
== 00:00
In case of authentication failure.
