Page #38 background image
VIRDI 4000
TM
User’s Manual
38
UNION COMMUNITY Co., Ltd. 44-3 Hyundai Topics Building, Bangi-dong,
Songpa-gu, Seoul, Korea 138-050, Tel: 82-2-6488-3000, Fax: 82-2-6488-3099,
E-Mail:sales@unioncomm.co.kr, http://www.unioncomm.co.kr/eng
3.5.3. Doorlock settings
In the main menu, press [3] to select “3. Option” and the following screen
appears:
1. Application
2. Verify Option
3. Set Doorlock
4. Sound Control
5. Time Setting
6. Other Setting
Press [3] for door settings.
3.5.3.1. Door opening time settings.
[*] [3] [3]
<Open Duration>
(00-30):03
Default setting: ‘03’ (unit: sec.)
This is used to set the door opening time after authentication is successful.
This only applies to the door opening time for strike type locks and not
applicable to dead bolt type locks or automatic doors.
If set to ‘00’, the door in access control mode is not controlled. Therefore, the
‘00’ setting is only possible for time & attendance mode, where there’s no
need for lock control.
After this setting is complete, press [ENTER] to move to the next setting.
3.5.3.2. Door status monitor
[*] [3] [3] [ENTER]
<Door Monitor>
[0/1=NO/2=NC]:0
Default setting: ‘0’
- ‘0’: NW – No monitoring
- ‘1’: NO – Dead bolt type lock or automatic door
- ‘2’: NC - Strike type lock
‘0’ setting is for no monitoring, ‘1’ setting is for dead bolt type locks or
