3.8.4. Wiegand output settings
[*] [6] ‘084265’ [ENTER] [4]
Wiegand Out:0
0=None 1=26bit
2=34bit
Default setting: ‘0’
The default setting is ‘0’. If Wiegand output from the local terminal is needed for
external access controller with Wiegand input, an administrator can set this
setting as ‘1’ or ‘2’.
- In case of ‘1’ setting, “site code [1 byte] and user ID [2 bytes]” are transmitted
through Wiegand output port. User ID should be set as less than 4 digits.
- In case of ‘2’ setting, “site code [1 byte] and user ID [3 bytes]” are transmitted
through Wiegand output port. User ID should be set as less than 7 digits.
This setting is not related to external Wiegand reader.
In cases of ‘1’ or ‘2’ settings, the below-mentioned site code should be set.
<Site Code>
(0-255):000
Default setting: ‘000’
An administrator can assign the site code, from 0 to 255, which is transmitted
together with a user ID.
After this setting is complete, press [ENTER] to move to the upper menu.
<Bypass>
0=Off
1=Wiegand
2=Terminal
Default setting: ‘0’
1. Data input Wiegand data is printed as wiegand
2. Input card data from terminal is printed as wiegand
3.8.5. System configuration settings
1. Set Fn-Key
2. Card Reader
3. FP-Sensor
4. Wiegand
5. System Config
6. Initialize
Press [5] for system configuration settings.
