VIRDI 4000
TM
User’s Manual
47
UNION COMMUNITY Co., Ltd. 44-3 Hyundai Topics Building, Bangi-dong,
Songpa-gu, Seoul, Korea 138-050, Tel: 82-2-6488-3000, Fax: 82-2-6488-3099,
E-Mail:sales@unioncomm.co.kr, http://www.unioncomm.co.kr/eng
1:N Level
(3-9):5
Default setting: ‘5’
This is to set the 1:N authentication security level between the fingerprint
captured from the fingerprint input window and all fingerprints in a terminal
which are allowed for 1:N authentication.
For your information, 1:N authentication level is not set for respective users but
only for a terminal.
Press [ENTER] to move to the next setting.
3.8.3.3. Intelligent-Capture settings
<I-Capture>
(N=0/Y=1):1
Default setting: ‘1’
This adjusts the sensor settings to automatically enhance good fingerprint
detection capability by reducing bad influences coming from humid fingers
and/or residual fingerprints which are left on a sensor window due to sweat
and/or contaminants on fingertip.
- If it is set to ‘0’, fingerprint capturing time is shorter but the authentication rate
for dry or wet finger becomes lower.
- If it is set to ‘1’, fingerprint capturing time becomes longer than that of the ‘0’
setting but the authentication rate increasing. Therefore, a ‘1’ setting is
recommended.
After the setting is complete, press [ENTER] to move to the upper menu.
3.8.3.4. LFD Label Setting
<LFD>
(0-3):0
Default setting: ‘0’
When setting the fake fingerprint level to 0, security levels are comparably low.
If 3, security level is the highest.
After input set value [ENTER] to upper menu.
