VIRDI 4000
TM
User’s Manual
44
UNION COMMUNITY Co., Ltd. 44-3 Hyundai Topics Building, Bangi-dong,
Songpa-gu, Seoul, Korea 138-050, Tel: 82-2-6488-3000, Fax: 82-2-6488-3099,
E-Mail:sales@unioncomm.co.kr, http://www.unioncomm.co.kr/eng
using this function, an administrator can read a card number when it is placed
on the terminal mounted card reader. This is to register the placed card with the
server. When this LCD screen pops up and an administrator places a card on
the terminal, the card number shows in the LCD screen.
To exit from this setting, press [#] to move to the upper menu.
3.7.3. Fire Sensing Link
◆ [*] [5] ◆[3]
<Fire Sensing Check>
[0/1=NO/2=NC]:0
Default setting: ‘0’
Linking a Fire Sensor with the terminal. On sensing a fire, send a fire-sensing
signal to switch the door to open.
After setting, press [Enter] to upper menu.
3.8. Device settings
In the main menu, press [6] to select “6. Device”, and the following screen,
asking for a password, appears:
In most cases there is no need to modify the device settings after installation.
Therefore, be careful not to modify the device settings without any obvious
reasons.
<Input PW>
PW:
This previously factory set password is to call
administrator’s attention, and is fixed and should
not be changed.
Input ‘084265’ as the previously set password and press [ENTER] to show the
detailed setting items.
3.8.1. Function key settings
◆ [*] [6] ‘084265’ [ENTER] ◆[1]
<Key On/Off>
1=F1:0 2=F2:0
3=F3:0 4=F4:0
5=Ent:O 6=FP:O
Default setting: all ‘O’
