VIRDI 4000
TM
User’s Manual
53
UNION COMMUNITY Co., Ltd. 44-3 Hyundai Topics Building, Bangi-dong,
Songpa-gu, Seoul, Korea 138-050, Tel: 82-2-6488-3000, Fax: 82-2-6488-3099,
E-Mail:sales@unioncomm.co.kr, http://www.unioncomm.co.kr/eng
== 00:00
Non-registered user ID.
== 00:00
During the authentication request to the
authentication server, a network problem occurred
or the network was disconnected.
4.1.3. [1:N] fingerprint authentication
This authentication is only allowed for users who are registered as 1:N
authentication setting.
▶ If a user places their finger close to the fingerprint sensor when auto sensing
is running, the light on the fingerprint input window turns on to detect the
fingerprint and the authentication result is displayed on the LCD window.
▶ When you press the function key, voice information like ‘please enter your
fingerprint’ follows. When a fingerprint is input, the authentication result is
displayed on the LCD window.
== 00:00
In the main screen, press the function key.
▼
== 00:00
Place your finger close to the input window when you
hear the voice message “Please enter your
fingerprint”. Do not remove your finger until you hear
a “ppig” buzzer sound.
▼
== 00:00
If authentication is successful, a success message is
displayed on the LCD together with a voice message
“You are authorised”. The door LED turns on and
door relay runs.
The default screen appears after 1~2 seconds. The
door LED turns off and door relay releases after the
door open setting time has elapsed.
※ Error message: The following error message appears together with a voice
message “Please try again”.
== 00:00
In case of authentication failure
== 00:00
If the connection method is SN – refer to 3.4.2.
Connection [NS / SN / NO] mode settings - and
there is no user to whom 1:N authentication is
allowed in the terminal.
To Next Page
