All rights reserved 51 Servicemanual_UR3_en_rev3.1.2
8. Replace Motherboard.
9. Insert the 6 cables in correct connectors.
10. Re-install USB stick for UR system SW.
11. Carefully put back the aluminum cover plate, make sure to mount it correct and fix it with
the 3 screws
1
3
4
6
2
5
