Universal Robots ur3 User Manual

All rights reserved 17 Servicemanual_UR3_en_rev3.1.2
3.1.5 Torque values
UR3 torque values
CONNECTION
TORQUE
HEAD SIZE
Base mounting bracket
J0 Base
3.0Nm
Torx T20
[J0] Base
J[1] Shoulder
3.0Nm
Torx T20
[J1] Shoulder
Upper arm
3.0Nm
Torx T20
Upper arm
[J2] Elbow
1.3Nm
Torx T10
[J2] Elbow
Lower arm
1.3Nm
Torx T10
Lower arm
[J3] Wrist 1
1.3Nm
Torx T10
[J3] Wrist 1
[J4] Wrist 2
1.3Nm
Torx T10
[J4] Wrist 2
[J5] Wrist 3
1.3Nm
Torx T10
[J5] Wrist 3
Tool mounting bracket
1.3Nm
Torx T10
Tool/ Gripper M6
10Nm
Blue lid: Base, Shoulder and Elbow
0.4Nm
Torx T10
Blue lid: Wrist 1, Wrist 2 and Wrist 3
0.4Nm
Torx T8
Attention: Click the torque tools 3 times before use to get the correct calibrated torque.
1.3Nm
Nm
1.3Nm
1.3Nm
1.3Nm
1.3Nm
1.3Nm
3.0Nm
3.0Nm
3.0Nm
10.0Nm
Nm
