MIXING INDOOR (MIX INDR) (See fig. q)
1) Go to MIX INDR item field in Adjust Menu
2) Set to the room temperature used in original heat-loss
calculations for the building (Normally 65 to 70°F)
DIP SETTING: Mixing Reset
RANGE: 35 to 100°F (2 to 38°C)
DEFAULT: 70°F (21°C)
MIXING DESIGN (MIX DSGN) (See fig. r)
1) Go to MIX DSGN item field in Adjust Menu
2) Set to the design supply water temperature calculated in
heat-loss calculation for the mixing zones
DIP SETTING: MIXING RESET
RANGE: 70 to 220°F (21 to 104°C)
DEFAULT: 110°F (43°C)
47
PROGRAMMING
PROGRAMMING - Step 1 - Programming the Control
