Upright AB38 Service & Parts Manual

Section
7.2
7-22 AB38 Work Platform
Illustrated Parts Breakdown
SLEW MOTOR, WORM DRIVE UNIT
& SLEW BEARING ASSEMBLY
500284-001
ITEM PART NO. DESCRIPTION QTY.
1 500284-000 AB38 WORM DRIVE UNIT & SLEW 1
BEARING ASSEMBLY
* 500280-000 BOLT 5/8” -11 UNC x 3 1/2” 16
* 500281-000 WASHER M16 HARDENED 16
2 500285-000 AB38 SLEW MOTOR 1
* 500285-001 SEAL KIT 1
* 500282-000 BOLT 1/2” -13 UNC x 1 1/2” 2
* 056021-012 WASHER M12 SPRING 2
