Upright AB38 Service & Parts Manual

Section
7.2
7-20 AB38 Work Platform
Illustrated Parts Breakdown
REAR & FRONT WHEEL KIT
(WHITE - NON MARKING)
SERIAL 1297 TO CURRENT
500494-000
ITEM PART NO. DESCRIPTION QTY.
1 057578-000 WHEEL NUT - M14 10
2 057668-001 REAR WHEEL TYRE & RIM ASSY. 2
3 057666-000 WHEEL NUT - M16 10
4 057667-003 FRONT WHEEL TYRE & RIM ASSY. 2
REAR & FRONT WHEEL KIT
(NON MARKING)
ITEM PART NO. DESCRIPTION QTY.
1 057578-000 WHEEL NUT - M14 10
2 058971-000 REAR WHEEL TYRE & RIM ASSY. 2
3 057666-000 WHEEL NUT - M16 10
4 058970-000 FRONT WHEEL TYRE & RIM ASSY. 2
REAR & FRONT WHEEL KIT
(BLACK)
ITEM PART NO. DESCRIPTION QTY.
1 057578-000 WHEEL NUT - M14 10
2 057668-000 REAR WHEEL TYRE & RIM ASSY. 2
3 057666-000 WHEEL NUT - M16 10
4 057667-001 FRONT WHEEL TYRE & RIM ASSY. 2
