7-16 AB38 Work Platform
Illustrated Parts Breakdown
TRACTION MOTOR ASSEMBLY
057568-000 : RIGHT HAND MOTOR
058834-000 : LEFT HAND MOTOR
ITEM PART NO. DESCRIPTION QTY.
1 - MOTOR MOUNTING FACE 1
2 - SEAL 1
3 - CIRCLIP 1
4 - BEARING 1
5 - COOLING FAN 1
6 - COMMUTATOR 1
7 - BEARING 1
8 - FIELD WINDINGS 1
9 - COMMUTATOR COVER 1
10 - BRUSH BOXES SUPPORT 1
11 - END FACE 1
12 - VENT / INSPECTION CAP 4
13 057698-000 BRUSH 4
14 057699-000 BRUSH SPRINGS 4
15 057569-001 TACHO ADAPTOR KIT 1
16 057569-000 TACHO 1
