Upright AB38 Service & Parts Manual

Section
7.2
7-14 AB38 Work Platform
Illustrated Parts Breakdown
DRIVE REDUCTION GEARBOX ASSEMBLY
057580-000
ITEM PART NO. DESCRIPTION QTY.
1 - COUPLING 1
2 - EXPANSION PLUG 1
3 - STEEL DISC 1
4 - BRONZE DISC 1
5 - O-RING 1
6 - SPACER 1
7 - O-RING 1
8 - ANTI-EXTRUS. RING 1
9 - PISTON 1
10 - SPRING 12
11 - O-RING 1
12 - ANTI-EXTRUS. RING 1
13 - OIL SEAL 1
14 - END PLATE 1
15 - O-RING 1
16 - CIRCLIP 1
17 - HUB 1
18 - BEARING 1
19 - CIRCLIP 1
20 - PLANET SHAFT 1
21 - PLANET CARRIER 1
22 - CIRCLIP 1
23 - THRUST WASHER 3
24 - NEEDLE ROLLER 84
25 - PLANET GEAR 3
26 - THRUST WASHER 3
27 - CIRCLIP 3
28 - SUN PINION 1
29 - O-RING 1
30 - BEARING 1
31 - RETAINING RING 1
32 - RETAINING RING 1
NOTE: ITEMS 5,7,8,11,12,13,15,29,44 & 46 FORM
THE SEAL KIT FOR THE DRIVE
REDUCTION GEARBOX ASSEMBLY.
THE PART NUMBER FOR THE
COMPLETE SEAL KIT IS 057580-010
ITEM PART NO. DESCRIPTION QTY.
33 - INPUT FLANGE 1
34 - SCREW 8
35 - SPACER 1
36 - CIRCLIP 1
37 - BEARING 1
38 - COUPLING 1
39 - BEARING 1
40 - PIN 1
41 - SPRING 1
42 - SUN PINION 1
43 - CIRCLIP 1
44 - O-RING 1
45 - THRUST WASHER 1
46 - O-RING 1
47 - RING + BEARING 1
48 - PLANET SHAFT 3
49 - SPINDLE 1
50 - THRUST WASHER 3
51 - THRUST WASHER 3
52 - NEEDLE ROLLER 75
53 - SPACER 3
54 - PLANET GEAR 3
55 - NEEDLE ROLLER 75
56 - THRUST WASHER 3
57 - THRUST WASHER 3
58 - WASHER 2
59 - PLUG 2
60 O57580-002 STUD M15 X 1.5 5
61 - PIN 1
62 - SCREW 1
63 - CIRCLIP 1
