Section

7.2

7-26 AB38 Work Platform

Illustrated Parts Breakdown

LOWER LIFT CYLINDER ASSEMBLY

058460-000

ITEM PART NO. DESCRIPTION QTY.

1 - CYLINDER BODY 1

2 058887-000 EMERGENCY LOWERING VALVE 1

SERIAL NUMBERS #1501-1522

500397-000 EMERGENCY LOWERING VALVE 1

SERIAL NUMBERS #1523-CURRENT

3 058728-000 SINGLE OVERCENTRE VALVE 1

4 - END CAP 1

5 - ROD AND END PIVOT 1

6 SEE NOTE U-RING ROD SEAL 1

7 SEE NOTE ROD SEAL 1

8 SEE NOTE WIPER 1

9 SEE NOTE BACK UP 0-RING 1

10 SEE NOTE O-RING 1

11 - SPACER 1

12 SEE NOTE PISTON O-RING 1

13 - PISTON HEAD 1

14 SEE NOTE PISTON SEAL 1

15 - PISTON LOCKNUT 1

16 - WASHER 1

17 058447-000 AB38 LOWER LIFT CYLINDER BOSS 2

18 057048-000 GREASE NIPPLE 3

19 058516-000 AB38 BOSS CAPHEAD SCREW M8 8

NOTE: ITEMS 6 TO 10 INCLUSIVE, 12 & 14

FORM THE SEAL KIT FOR THE AB38

LOWER LIFT CYLINDER. THE PART

NUMBER FOR THIS SEAL KIT IS

500457-000

NOTE: ITEMS 17, 18 & 19 ARE NOT INCLUDED

AS PART OF THE CYLINDER

ASSEMBLY.
