Section

7.2

7-2 AB38 Work Platform

Illustrated Parts Breakdown

FINAL ASSEMBLY AB38 -

500200-001 (ANSI Version)

500200-000 (CE Version)

ITEM PART NO. DESCRIPTION QTY.

- 500202-000 Chassis Assembly -

- 500201-000 Booms and Posts Assembly -

- 057603-000 Cage and Cradle Assembly -

- 057580-000 Drive Reduction Gearbox Assembly -

- 057568-000 Traction Motor Assembly - Right Hand -

058834-000 Traction Motor Assembly - Left Hand -

- 057530-000 Motor / Pump Assembly -

- 500494-000 Rear & Front Wheel Assembly -

- 500284-001 Pinion Gearbox & Slew Bearing Assy. -

- 500261-000 Manifold Block Assembly -

- 058460-000 Lower Lift Cylinder Assembly -

- 058462-000 Upper Lift Cylinder Assembly -

- 058461-000 Telescopic Cylinder Assembly -

- 058463-000 Steering Cylinder Assembly -

- 058734-000 Master Cylinder Assembly -

058735-000 Slave Cylinder Assembly -

- 500483-000 Pump Motor Control Unit Assembly -

- 500490-000 Lower Control Box Assembly -

- 500491-000 Upper Control Box Assembly -

- 500482-000 Circuit Board Box & Harnesses -

- - Cables & Electrical Components -

- 500360-000 Hose Assembly -

- - Decal Kit -
