Upright AB38 Service & Parts Manual

Section
7.2
7-18 AB38 Work Platform
Illustrated Parts Breakdown
MOTOR/PUMP ASSEMBLY
057530-000
ITEM PART NO. DESCRIPTION QTY.
1 058862-000 HYDRAULIC PUMP 1
* 058862-001 SEAL KIT 1
2 058847-000 COUPLING 1
3 - OIL SEAL 1
4 - PUMP MOUNTING FACE 1
5 - CIRCLIP 1
6 - BEARING 1
7 - CIRCLIP 1
8 - CIRCLIP 1
9 - COOLING FAN 1
10 - COMMUTATOR 1
11 - BEARING 1
12 - COMMUTATOR COVER 1
13 - BRUSH HOUSING SUPPORT 1
14 058863-000 BRUSH 4
15 - END HOUSING 1
16 - TERMINAL BLOCK 1
17 - VENT / INSPECTION CAP 4
NOTE: THE PART NUMBER FOR THE
MOTOR ASSEMBLY (ALL ITEMS FROM
2 TO 17) IS 058861-000
