Schematics
Section
6-3AB38 Work Platform
6.1. Electrical Schematics
J1 Harness
6.1
1
1
1
12
12
12
A
B
C
SECTION A-A
INSERTION VIEW
ROTATED 90° CW
41
41
25
1
26
13
3
27
4
42
40a
28
29
17
5
43
43
43
43
43
43
43
43
43
43
43
43
43
43
43
43
43
44
44
44
44
44
44
44
44
44
44
44
38
33
21
10
38
22
38
34
38
11
38
23
24
32
37 REF
39
20
39
8
39
31
39
19
37
12
36
39
30
7
A
A
40b
WIRE INFORMATION
ITEM NO. POSITION COLOR ITEM NO. POSITION COLOR ITEM NO. POSITION COLOR
1 A1 RED 13 B1 WHITE 25 C1 BLACK
2 A2 NOT USED 14 B2 NOT USED 26 C2 ORANGE
3 A3 GREEN 15 B3 NOT USED 27 C3 BLACK
4 A4 BLACK 16 B4 NOT USED 28 C4 WHITE/BLACK
5 A5 BROWN 17 B5 YELLOW 29 C5 GREY
6 A6 NOT USED 18 B6 NOT USED 30 C6 BLACK
7 A7 GREY 19 B7 BLUE/PINK 31 C7 BLUE
8 A8 ORANGE 20 B8 RED/YELLOW 32 C8 BROWN
9 A9 NOT USED 21 B9 VIOLET 33 C9 WHITE
10 A10 BLACK/ORANGE 22 B10 GREEN 34 C10 RED
11 A11
ORANGE/VIOLET
23 B11 YELLOW 35 C11 NOT USED
12 A12 RED/WHITE 24 B12
WHITE/YELLOW
36 C12 WHITE/RED
JUMPER INFORMATION
37 FROM A12 RED/WHITE 20 546 (21.5")
38 FROM B9 VIOLET 20 203 (8.0") 39 FROM C6 BLACK 20 203 (8.0")
40a FROM C4 WHITE/BLACK 20 203 (8.0")
40b FROM C4 WHITE/BLACK 20 127 (5.0")
