Upright AB38 Service & Parts Manual

Section
7.2
7-44 AB38 Work Platform
Illustrated Parts Breakdown
ITEM PART NO. DESCRIPTION QTY.
1 500357-000 HOSE ASSY, 1/2” M1T 267 mm 1
B90-B90
PUMP TO MANIFOLD
2 500353-000 HOSE ASSY, 1/4” M1T 6630 mm 1
B90-B90
MANIFOLD TO MASTER CYLINDER
3 500353-000 HOSE ASSY, 1/4” M1T 6630 mm 1
B90-B90
MANIFOLD TO MASTER CYLINDER
4 500228-000 HOSE ASSY, 1/4” M1T 8900 mm 1
B90-B90
MASTER TO SLAVE CYLINDER
5 500228-000 HOSE ASSY, 1/4” M1T 8900 mm 1
B90-B90
MASTER TO SLAVE CYLINDER
6 500358-000 HOSE ASSY, 3/8” M1T 190 mm 1
B90-B90
PUMP TO MANIFOLD
7 500354-000 HOSE ASSY, 1/4” M1T 1280 mm 1
B90-B90
MANIFOLD TO STEERING CYLINDER
8 500354-000 HOSE ASSY, 1/4” M1T 1280 mm 1
B90-B90
MANIFOLD TO STEERING CYLINDER
9 500226-000 HOSE ASSY, 3/8” M1T 1700 mm 1
B90-B90
MANIFOLD TO SLEW MOTOR
10 500226-000 HOSE ASSY, 3/8” M1T 1700 mm 1
B90-B90
MANIFOLD TO SLEW MOTOR
11 500351-000 HOSE ASSY, 1/4” M1T 1750 mm 1
B90-B90
MANIFOLD TO LOWER LIFT CYLINDER
12 500351-000 HOSE ASSY, 1/4” M1T 1750 mm 1
B90-B90
MANIFOLD TO LOWER LIFT CYLINDER
13 500352-000 HOSE ASSY, 1/4” M1T 6650 mm 1
B90-B90
MANIFOLD TO UPPER LIFT CYLINDER
14 500352-000 HOSE ASSY, 1/4” M1T 6650 mm 1
B90-B90
MANIFOLD TO UPPER LIFT CYLINDER
15 500227-000 HOSE ASSY, 3/8” M1T 7200 mm 1
B90-BF
MANIFOLD TO TELESCOPIC CYLINDER
16 500227-000 HOSE ASSY, 3/8” M1T 7200 mm 1
B90-BF
MANIFOLD TO TELESCOPIC CYLINDER
17 500356-000 HOSE ASSY, 1/4” M1T 1270 mm 1
BF-B90
MANIFOLD TO BRAKE T PIECE
18 500355-000 HOSE ASSY, 1/4” M1T 430 mm 1
BF-B90
T PIECE TO BRAKE
19 500355-000 HOSE ASSY, 1/4” M1T 430 mm 1
BF-B90
T PIECE TO BRAKE
20 058352-000 T PIECE 1
HOSE ASSEMBLY
500262-000
EXPLANATION OF HYDRAULIC TERMINOLOGY
BF STRAIGHT FEMALE FITTING
B90 SWEPT 90º FITTING
M1T MEGAFLEX HOSE
EXAMPLE:
1/2” M1T 85mm B90-BF @ 180º
FITTING TYPE
LENGTH OF HOSE
TYPE OF HOSE
FITTING TYPE
ORIENTATION OF FITTINGS
DIAMETER OF HOSE
