Upright AB38 Service & Parts Manual

iAB38 Work Platform
SERVICE & PARTS
MANUAL
AB38
Aerial Work Platform
This manual (500422-001) covers serial Numbers 2890 to 04243
When contacting UpRight Powered Access for service or parts
information, be sure to include the MODEL and SERIAL NUMBERS
from the equipment nameplate (nameplate types shown below).
The AB38 Work Platform meets and exceeds the requirements
of both prEN280 and ANSI A92.5 (1992).
500422-001
01/05
AB38 Work Platform
t
AB38 199
11.5 m 3550 kg
215 kg 2 Persons + 55 kg Equipment
400 N 12.5 m/s
0
o
48V
36% 240V
1.1 m/s 4 kW
MODEL SERIAL NO.
MAX PLATFORM HEIGHT UNLADEN WEIGHT
MAX. PLATFORM LOAD
MAX. LATERAL FORCE MAX. WIND SPEED
MAX. CHASSIS INCLINATION BATTERY VOLTAGE
MAX. GRADEABILITY CHARGER INPUT VOLTAGE
MAX. FORWARD SPEED NOMINAL POWER
UpRight
MODEL SERIAL NO.
MAX. PLATFORM LOAD
MAX. PLATFORM HEIGHT UNLADEN WEIGHT
MAX. PLATFORM REACH
MAX. LATERAL FORCE MAX. WIND SPEED
MAX. CHASSIS INCLINATION MAX. GRADEABILITY
MAX. HYDRAULIC PRESSURE
BATTERY VOLTAGE CHARGER INPUT VOLTAGE
MAX. FORWARD SPEED NOMINAL POWER
AB38N 199
475 lbs (2 Persons + 120 lbs)
38 ft. 7,825 lbs
18 ft. 4 in
90 lbs 28 mph
0
o
36%
2700 psi
48V dc 110/220V
2.5 mph 5.4 hp
Nameplate
The Serial Number of the Work
Platform is also stamped on the
inside of the Chassis, close to the
Steering Cylinder.
