Upright AB38 Service & Parts Manual

Section
7.2
7-8 AB38 Work Platform
Illustrated Parts Breakdown
ITEM PART NO. DESCRIPTION QTY.
1 057521-003 CAGE RAIL ASSY. 1
2 057524-000 DROP BAR ASSY. 1
3 057523-000 CONTROL BOX MOUNTING PLATE 1
4 501864-000 AB38 UPPER CONTROL BOX 1
5 010076-000 MANUAL HOLDER 1
6 501970-000 AB38 CAGE FLOOR WELDMENT 1
7 058251-000 LADDER LOCKING LATCH 1
8
057348-000 LADDER
1
9
501886-000 OVERLOAD UNIT(Ansi 509791-000)
1
10 056066-012 M12 NYLOCK NUT 2
11 056069-016 M16 WASHER 8
12 503101-045 M16 X 45 HEX HEAD SCREW 8
13 056069-012 M12 WASHER 4
14 058494-040 M12 X 40 HEX HEAD SCREW 2
15 501971-000 CAGE CRADLE WELDMENT 1
CAGE & CRADLE ASSEMBLY(STANDARD)
057603-000
(501864-000 is not included as part of this assembly)
Note : Ensure that items 10 and 14 (M12
screw and drilled nut with pin) remain loose,
these are safety bolts.
(ANSI is Without Overload)
1
