Section

7.2

7-10 AB38 Work Platform

Illustrated Parts Breakdown

CAGE ROTATOR ASSEMBLY(OPTION)

500905-000

(501864-000 is not included as part of this assembly)

Note : Ensure that items 11 and 18 (M12

screw and drilled nut with pin) remain loose,

these are safety bolts.

ITEM PART NO. DESCRIPTION QTY.

1 501864-000 UPPER CONTROL BOX. 1

2 500973-000 MOUNTING PLATE. 1

3 500985-000 ROTATING HANDLE 1

4 500922-000 GEARBOX 1

5 500905-034 HANDLE 1

6 500905-030 DRIVE SHAFT 1

7 057524-000 DROP BAR ASSY 1

8 057521-001 CAGE RAIL ASSY 1

9 501970-000 WELDMENT, CAGE BASE 1

10 501886-000 OVERLOAD UNIT (Ansi 509791-000) 1

11 058494-040 M12 X 40 HEX HEAD SCREW 2

12 056069-016 M16 WASHER 8

13 503101-040 M16 X 40 HEX HEAD SCREW 8

14 500924-000 48mm THRUST WASHER 1

15 501971-001 CAGE CRADLE WELDMENT 1

16 500993-000 45mm BUSHING X 30mm LONG 2

17 501972-000 WELDMENT, CAGE LINK 1

18 058066-012 M12 NYLOCK NUT 2

19 057347-001 LADDER 1

20 058251-000 LOCKING CATCH 1

21 057405-000 LADDER BUSHING 2

(ANSI is Without Overload)

22 509466-000 ROLL PIN ROTATE LINK 1
