Utax P-C2660DN Service Manual

2PS/2PT
2-3-16
YC10 1 +24V0 O 24 V DC 24 V DC power to RFM
Connected to
right fan
motor
2 RFANDRN O 0/12/24 V DC RFM: Full speed/Half speed/Off
YC12 1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 NC - - Not used
5 GND - - Ground
YC13 A1 VBUS_A O 5 V DC 5 V DC power output
Connected to
USB
A2 D-_A I/O - USB data signal
A3 D+_A I/O - USB data signal
A4 GND_A - - Ground
B1 VBUS_B I 5 V DC 5 V DC power output
B2 D-_B I/O - USB data signal
B3 D+_B I/O - USB data signal
B4 GND_B - - Ground
YC14 1 +5V1 I 5 V DC 5 V DC power output
Connected to
e-KUIO slot
2 GND - - Ground
3 RST_KUIO0 O 0/3.3 V DC FAX reset signal
4 +5V2_EKUIO I 5 V DC 5 V DC power output
5 GND - - Ground
6 WAKE_UP_K
UIO0
I 0/3.3 V DC FAX job interrupt signal
7 AUDIO I ANALOG Audio signal
8 NC - - Not used
9 NC - - Not used
10 NC - - Not used
11 GND - - Ground
12 NC - - Not used
13 NC - - Not used
14 GND - - Ground
15 NC - - Not used
16 NC - - Not used
17 GND - - Ground
18 USBH_DP I/O 0/3.3 V DC (pulse) USB Data +
19 USBH_DN I/O 0/3.3 V DC (pulse) USB Data -
20 VBUS_USBH O 0/3.3 V DC VBUS signal
