V2 CITY2+L - IMPORTANT REMARKS; DECLARATION OF CONFORMITY; TECHNICAL SPECIFICATIONS

ENGLISH
- 26 -
1 - IMPORTANT REMARKS
ForanyinstallationproblempleasecontactourCustomerService
atthenumber+39-0172.812411operatingMondaytoFriday
from8:30to12:30andfrom14:00to18:00.
V2 has the right to modify the product without previous
notice; it also declines any responsibility to damage or
injury to people or things caused by improper use or wrong
installation.
m Please read this instruction manual very carefully
before installing and programming your control unit.
• Thisinstructionmanualisonlyforqualiedtechnicians,who
specialize in installations and automations.
• Thecontentsofthisinstructionmanualdonotconcerntheend
user.
• Everyprogrammingand/oreverymaintenanceserviceshould
bedoneonlybyqualiedtechnicians.
AUTOMATION MUST BE IMPLEMENTED IN COMPLIANCE
WITH THE EUROPEAN REGULATIONS IN FORCE:
EN 60204-1 (Machinerysafety.electricalequipmentof
     machines,part1:generalrules)
EN 12445  (Safeuseofautomatedlockingdevices,
test methods)
EN 12453  (Safeuseofautomatedlockingdevices,
requirements)
• Theinstallermustprovideforadevice(es.magnetotermical
switch)ensuringtheomnipolarsectioningoftheequipment
fromthepowersupply.Thestandardsrequireaseparationof
thecontactsofatleast3mmineachpole(EN60335-1).
• Aftermakingconnectionsontheterminalboard,useone
hoseclamptoxdangerousvoltagewiresneartheterminal
boardandanotherhoseclamptoxsafetylowvoltagewires
usedforaccessoriesconnection;thisway,incaseofaccidental
detachmentofaconductingwire,dangerousvoltagepartswill
notcomeintocontactwithsafetylowvoltageones.
• TheplasticcasehasanIP55insulation;toconnectexibleor
rigidpipes,usepipettingshavingthesameinsulationlevel.
• Installationrequiresmechanicalandelectricalskills,thereforeit
shallbecarriedoutbyqualiedpersonnelonly,whocanissue
theComplianceCerticateconcerningthewholeinstallation
(EEC Machine Directive 89/392, Annex IIA).
• Theautomatedvehiculargatesshallcomplywiththefollowing
rules:EN12453,EN12445,EN12978aswellasanylocalrule
inforce.
• Alsotheautomationupstreamelectricsystemshallcomplywith
thelawsandrulesinforceandbecarriedoutworkmanlike.
• Thedoorthrustforceadjustmentshallbemeasuredbymeans
ofapropertoolandadjustedaccordingtothemax.limits,
which EN 12453 allows.
• Werecommendtomakeuseofanemergencybutton,tobe
installedbytheautomation(connectedtothecontrolunit
STOPinput)sothatthegatemaybeimmediatelystoppedin
caseofdanger.
• Alwaysremembertoconnecttheearthaccordingtocurrent
standards (EN 60335-1, EN 60204-1).
2 - DECLARATION OF CONFORMITY
V2S.p.A.herebydeclarethatCITY2+productsconformtothe
essentialrequirementsestablishedinthefollowingdirectives:
• 2004/108/CEE(EMCDirectiveinaccordancewithstandards
EN 55014-1, EN 55014-2, EN 61000-3-2, 61000-3-3)
• 2006/95/CEE(LowVoltageDirectiveinaccordancewith
standards EN 60335-1 + EN 60335-2-103)
• 99/05/CEE(RadioDirectiveinaccordancewithstandard
EN 301 489-3)
• DirectiveRoHS22011/65/CE
Racconigi,12/01/2010
V2S.p.A.legalrepresentative.
Cosimo De Falco
3 - TECHNICAL SPECIFICATIONS
CITY2+ CITY2+L CITY2+BC
Powersupply 230V/50Hz 230V/50Hz 24Vdc
Max total load 250W 200W 250W
Maxloadforeach
motor
150W 100W 150W
Dutyclcle 40% 40% 40%
Max accessories
load 24Vdc
7W 7W 7W
Protectionfuse 2,5A 2,5A -
Weight 3000g 1000g 1000g
Dimensions 295 x 230 x 100 mm
Working
temperature
-20 ÷ +60°C
Protection IP55
