ENGLISH

- 31 -

5.11 - EXTERNAL AERIAL

Wesuggesttousetheexternalaerial(model:ANS433)inorderto

guaranteethemaximalrange.

Connect the antenna hot pole to terminal L1 (ANT)ofthecontrol

unitandthebraidingtoterminalL2 (ANT-).

5.12 - PLUG IN RECEIVER

CITY2+controlunitissuitableforplugginginaMRreceiver.

m WARNING: Pay attention to the way you connect the

removable modules.

MRmodulereceiverisprovidedwith4channelsandeachofthem

issuitableforacommandofCITY2+controlunit:

• CHANNEL1 g START

• CHANNEL2 g PEDESTRIAN START

• CHANNEL3 g STOP

• CHANNEL4 gCOURTESYLIGHT

m WARNING: Before programming 4 channels and

function logics read carefully the instructions of MR.

5.13 - ADI INTERFACE

TheADI(AdditionalDevicesInterface)interfaceofthecontrolunit

CITY2+ allows the connection to V2 optional modules.

RefertoV2catalogueortothetechnicalsheetstoseewhich

optionalmoduleswithADIinterfaceareavailableforthiscontrol

unit.

m WARNING: Please read the instructions of each single

module to install the optional modules.

Forsomedevices,itispossibletocongurethemodefor

interfacingwiththecontrolunit;inaddition,itisnecessaryto

enabletheinterfacesothatthecontrolunitcanprocessthe

signalsarrivingfromtheADIdevice.

Pleaserefertothei.AdiprogrammingmenutoenabletheADI

interfaceandaccessthedevicecongurationmenu.

TheADIdevicecansignalphotocell,edgeorstopalarms:

• Photocell alarms -thegatestopsmoving,whenthealarm

stopsopeningrestarts.

• Edge alarm -invertsmotionofthegatefor3seconds.

• Stop alarm-thegatestopsandcannotrestartuntilthealarm

stops.

V2 CITY2+L User Manual
