V2 CITY2+L - SAFETY RIBBONS; LOW VOLTAGE LIGHT (24 V); 230 V COURTESY LIGHT OR FLASHING LIGHT; LOCK

ENGLISH
- 29 -
5.7 - LOW VOLTAGE LIGHT (24V)
The CITY2+ controller has a 24 V DC output that allows
connections to a load up to 15 W.
Thisoutputcanbeusedtoconnectasignallightthatindicates
thatstatusofthegate,orforalowvoltageashinglight.
Connectthelowvoltagesignallightorashinglightwiresto
terminals Z1 (+) and Z2 (-).
m CAUTION: Pay attention to the polarity of the
connected device if necessary.
5.8 - 230V COURTESY LIGHT OR
FLASHING LIGHT
ThankstotheoutputCOURTESYLIGHTthecontrolunitallows
theconnectionofanelectricappliance(e.g.courtesylightor
gardenlights),controlledautomaticallyorbymeansofthespecial
transmitterkey.
Thecourtesylightterminalscanbealternativelyusedfora230V
ashinglightwithintegratedasher.
CAUTION: When the controller is operating on battery
power, the 230 V ashing light will not work.
TheoutputCOURTESYLIGHTisasimpleN.O.contactwithno
powersupply(themaximumratingoftherelayis5A-230V).
Connect the cables to terminals B1 and B2.
5.9 - LOCK
Anelectriclockcanbeassembledonthegate,toensureagood
closingofdoors.Makeuseofa12Vlock.
Connect lock cables to terminals K9 and K10 ofthecontrolunit.
5.6 - SAFETY RIBBONS
Thecontrolunitconsiderstwokindsofsafetyribbons,depending
ontheterminaltowhichtheyareconnected:
Type 1 (xed)
Theyaremountedonwallsoronotherxedobstaclesthatare
approachedbythegatedoorsduringtheopeningphase.
Whentype1safetyribbonsoperateduringthegateopening
phase,thecontrolunitwillclosethedoorsfor3seconds,thenit
standsstill;whentype1safetyribbonsoperateduringthegate
closingphase,thecontrolunitwillstandstillimmediately.
ThedirectionofthegateatnextcommandofSTARTor
PEDESTRIAN START depends upon the parameter STOP (it inverts
or continues the motion).
IftheinputSTOPisdisabled,thecommandmakesthemotion
continueinthesamedirection.IftheSTOPinputisdisabled,the
controlrestartsmotioninthesamedirectionitwastravellingprior
totheinterventionoftheedge.
Type 2 (mobile)
Theyaremountedtothedoorends.
Whentype2safetyribbonsoperateduringthegateopening
phase,thecontrolunitwillstandstillimmediately;whentype2
safetyribbonsoperateduringthegateclosing,thecontrolunit
willopenthedoorsfor3seconds,thenitwillstandstill.
ThedirectionofthegateatnextcommandofSTARTor
PEDESTRIAN START depends upon the parameter STOP (it inverts
orcontinuesthemotion).IftheinputSTOPisdisabled,the
command makes the motion continue in the same direction.
IftheSTOPinputisdisabled,thecontrolrestartsmotioninthe
samedirectionitwastravellingpriortotheinterventionofthe
edge.
Boththeinputcanmanagetheclassicsafetyedgewithn.c.
contactandtheconductiverubbersafetyedgewith8,2kohm
nominal resistance.
Connecttype1safetyribbonscablesbetweenterminals
L9 (EDGE1) and L11 (COM)ofthecontrolunit.
Connecttype2safetyribbonscablesbetweenterminals
L10 (EDGE2) and L11 (COM)ofthecontrolunit.
InordertomeettherequirementsoftheEN12978rules,itis
necessarytoinstallsafetyedgescontrolledbyacontrolunit
continuouslycheckingtheproperworking.Ifusingcontrolunits
suitedtothetestbypoweroutage,connectthepowersupply
cablesofthecontrolunitbetweenterminalsK7 (-) and K8 (+Test)
ofthecontrolunit.
Otherwise, connect them between terminals K6 (+) and K7 (-).
m WARNING:
• Makeuseofsafetyribbonshavingoutputswithnormallyclose
contact.
• Outputsofsamekindsafetyribbonsmustbeconnectedin
series.
