Vacon NX Service Manual

Fault codes and software
email: service@vacon.com Tel: +358 (0)201 212 575 Fax: +358 (0)204 335 091
79
4
F45 Device Parameter added
INDICATION ONLY
F45 displayed.
Check
subcode.
NOTE:
Read Service Bulletin 0303.
Available in software NXSV128 / NXPV122 or newer.
F45 appears if new option board of different type is inserted in same slot.
Option board parameters are set to default.
1: Control board
2: Control unit
3: Power board
4: Power unit
5: Adapter board
A: Slot A
B: Slot B
C: Slot C
D: Slot D
E: Slot E
Press reset.
Set option board prameters
as needed.
FIGURE 38. Fault code F45
