19Installation instructions for the electronicVED plus electric instantaneous water heater 0020149585_00
10 Technical data
Unit type
Art. no.
Unit
VED E 18/7 P
0010007723
VED E 21/7 P
0010007724
VED E 24/7 P
0010007725
VED E 27/7 P
0010007726
For supplying one or more draw-off points
1)
Design Appliance for wall-mounted installation
Configuration Bare wire heating coil
Capacity l 0.4
Dimensions width
Height
Depth
mm
mm
mm
240
481
100
Weight when filled with water kg 4.4
Performance characteristics Electronically regulated output
Water inlet temperature °C 1...60 1...25
Switch-on water volume l/min 3
Switch-off water volume l/min 2.5
Switch-on flow pressure MPa 0.015
Max. water flow rate l/min 6 7 8 9
Rated overpressure MPa 1
Rated output* (T of max. 38 K) kW 15.7/18.0 18.5/21.0 21.0/24.0 23.7/27.0
Minimum water resistance at 15 °C cm 900
Measuring voltage 3/PE~ 380/400 V; 50 Hz
Safety Complies with German and Austrian safety regulations; radio-shielded; does not
interact with the mains supply
Level of protection IP 25 = sprayed-water protection
Tab. 10.1 Technical data
1) = closed unit (pressure resistant)
* at 380/400 V
Technical data 10
