Operating instructions for the electronicVED plus electric instantaneous water heater 0020149585_00 3
1 Notes on the documentation
The following information is intended to help you
throughout the entire documentation. Further docu-
ments apply in combination with these instructions for
use.
We accept no liability for any damage caused by failure
to observe these instructions.
Other applicable documents
When operating the electronicVED plus, you must also
observe all operating instructions that are included with
other components of your system.
1.1 Storing documents
> Store these operating instructions and all other docu-
ments provided in such a way that they are available
whenever required.
1.3 Applicability of the instructions
These instructions apply for the following only:
Type designation Article number
VED E 18/7 P 0010007723
VED E 21/7 P 0010007724
VED E 24/7 P 0010007725
VED E 27/7 P 0010007726
Tab. 1.1 Identifying the unit
1.4 Identification plate
The unit's article number is part of the serial number. To
find out the serial and article numbers, refer to the iden-
tification plate. The identification plate can be found to
the right, next to the operator control panel, under the
cover.
Vaillant GmbH Remscheid / Germany
Serial - No.
VED E 18/7 P
21093500200752100006000000N3
18 kW; 400 V 3~ 50Hz
1MPa (10bar); p 15 >= 900 Ohm cm; IP 25
Observe operating- and installation manual
Appliance must be earthed
Fig. 1.1 Example of an identification plate
Explanation of the symbols on the identification plate
CE mark, see section 1.5
The VDE GS mark confirms that the
unit complies with standards and
has been tested for safety
Symbol confirming conformity with
the electromagnetic compatibility
standard
Ensure proper disposal at the end
of its useful life (not household
waste)
Read the operating and
installation instructions
21093500200752100006000000N3
Serial number as a bar code and in
plain text.
The 7th to 16th digits of the serial
number form the unit's article
number
1.5 CE label
CE labelling shows that, based on the type
overview, the units comply with the basic
requirements of the applicable directives.
