Valleylab ForceTriad - Page 98

Output Power vs. Resistance Graphs
9-24 ForceTriad User’s Guide
Bipolar Macro
Output power versus impedance
for Bipolar Macro power
Output power versus power
setting for Bipolar Macro power
Peak voltage versus power
setting for Bipolar Macro power
0
10
20
30
40
50
60
70
80
90
100
0 500 1000 1500 2000
50%
100%
Load Impedance (ohms)
Output power (watts)
0
10
20
30
40
50
60
70
80
90
0 20406080
Bip Macro Output
Power vs . Setting @
100ohm
Output power (watts)
Power Setting
0
50
100
150
200
250
0 20406080
Open Circuit Bipolar
Macro Peak Voltage
vs. Power Setting
Power Setting
Peak Voltage
