Valmet TS - Page 48

TS-150/6” TS-200/8”
Valmet TS 100 bar
Total weight of sensor: 38 kg Total weight of sensor: 78 kg Total weight of sensor: 126 kg
ANSI Class 600
D I N PN 100
JIS 63K
Flange drill standards:
1 inch = 2,54 mm
All dimensions are in mm (millimeters).
Main Dimensions
