under the sag limit (U<) or increases over the swell limit (U>).
There are four registers for both sags and swells in the fault
log. Each register will have start time, type (which phases),
duration, minimum, average, maximum voltage values of each
sag and swell event. Furthermore, there are total number of
sags and swells counters as well as total timers for sags and
swells.
The voltage power quality functions are located under the
submenu “U”.
Setting parameters of sags and swells monitoring:
Parameter: Value: Unit: Default: Description:
U> 20…150 % 110 Setting value of swell limit
U< 10…120 % 90 Setting value of sag limit
Delay 0.04…1.00 s 0.06
Delay for sag and swell
detection
SagOn On; Off - On Sag on event
SagOff On; Off - On Sag off event
SwelOn On; Off - On Swell on event
SwelOf On; Off - On Swell off event
Recorded values of sags and swells monitoring:
Parameter: Value: Unit: Description:
Count - Cumulative sag counter
Total - Cumulative sag time counter
Count - Cumulative swell counter
Total - Cumulative swell time counter
Sag/swell logs 1…4
Date - Date of the sag/swell
Time - Time stamp of the sag/swell
Type -
Voltage inputs that had the
sag/swell
Time s Duration of the sag/swell
Min1 %Un
Minimum voltage value during
the sag/swell in the input 1
Min2 %Un
Minimum voltage value during
the sag/swell in the input 2
Min3 %Un
Minimum voltage value during
the sag/swell in the input 3
Ave1 %Un
Average voltage value during the
sag/swell in the input 1
Ave2 %Un
Average voltage value during the
sag/swell in the input 2
Ave3 %Un
Average voltage value during the
sag/swell in the input 3
Max1 %Un
Maximum voltage value during
the sag/swell in the input 1
Recorded
values
Max2 %Un
Maximum voltage value during
the sag/swell in the input 2
