VAMP 260 Power monitoring unit
Operation and configuration
VAMP Ltd
6
Vamp 24h support phone : +358 (0)20 753 3264
VM260.EN004
2. User interface
2.1. General
The VAMP 260 power-monitoring unit can be controlled in
three ways:
Locally with the push-buttons on the unit front panel
Locally using a PC connected to the serial port on the front
panel or on the rear panel of the unit (both cannot be used
simultaneously)
Via the remote control port on the unit rear panel.
2.2. Unit front panel
The figure below shows the front panel of the unit and the
location of the user interface elements used for local control.
VY 062 B
Power
Error
Com
Alarm
Trip
A
B
C
VAMP 260
Power Monitoring Unit
1
3
2
4
Figure 2.2-1. Unit front panel.
1. LCD dot matrix display
2. Key pad
3. LED indicators
4. RS 232 serial communication port for PC
