Operation and configuration 2 Local panel user interface 2.2 Local panel operations
Main
menu
Number
of
menus
Description
ANSI
code
Note
Prg2 11 2nd programmable stage 4
Prg3 11 3rd programmable stage 4
Prg4 11 4th programmable stage 4
Prg5 11 5th programmable stage 4
Prg6 11 6th programmable stage 4
Prg7 11 7th programmable stage 4
Prg8 11 8th programmable stage 4
If2> 3 Second harmonic O/C stage 51F2 4
CBFP 10
Circuit breaker failure
protection
50BF 4
CBWE 5
Circuit breaker wearing
supervision
4
CTSV 1 CT supervisor 4
ArcI> 11
Optional arc protection stage
for phase-to-phase faults and
delayed light signal.
50ARC 4
ArcIo> 10
Optional arc protection stage
for earth faults. Current input
= I01
50NARC 4
ArcIo2> 10
Optional arc protection stage
for earth faults. Current input
= I02
50NARC 4
AR 4 Auto-reclose 79 8
OBJ 10 Object definitions 5
Lgic 2
Status and counters of user's
logic
1
CONF 9 Device setup, scaling etc. 6
Bus 11
Serial port and protocol
configuration
7
Diag 9 Device selfdiagnosis
Notes
1 Configuration is done with VAMPSET
2 Recording files are read with VAMPSET
3
The menu is visible only if protocol "ExternalIO" is selected for one of
the serial ports. Serial ports are configured in menu "Bus".
4 The menu is visible only if the stage is enabled.
5 Objects are circuit breakers, disconnectors etc.
6
There are two extra menus, which are visible only if the access level
"operator" or "configurator" has been opened with the corresponding
password.
7 Detailed protocol configuration is done with VAMPSET.
8 VAMP51 and VAMP52
2.2.2. Menu structure of protection functions
The general structure of all protection function menus is
similar although the details do differ from stage to stage. As an
VM50.EN004 VAMP 24h support phone +358 (0)20 753 3264
13
