9.2. Tests and environmental conditions
9.2.1. Disturbance tests
Emission EN 61000-6-4 / IEC 60255-26
- Conducted EN 55011 / IEC 60255-25
0.15 - 30 MHz
- Emitted EN 55011 / IEC 60255-25
30 - 1 000 MHz
Immunity EN 61000-6-2 / IEC 60255-26
- Static discharge (ESD) EN 61000-4-2 class IV / IEC 60255-22-2
8 kV contact discharge
15 kV air discharge
- Fast transients (EFT) EN 61000-4-4 class IV / IEC 60255-22-4, class A
4 kV, 5/50 ns, 2.5/5 kHz, +/-
- Surge EN 61000-4-5 class IV / IEC 60255-22-5
4 kV, 1.2/50 s, line-to-earth
2 kV, 1.2/50 s, line-to-line
- Conducted HF field EN 61000-4-6 class III / IEC 60255-22-6
0.15 - 80 MHz, 10 V
- Emitted HF field EN 61000-4-3 class III / IEC 60255-22-3
80 - 1000 MHz, 10 V/m
9.2.2. Test voltages
Insulation test voltage (IEC 60255-5) 2 kV, 50 Hz, 1 min
Surge voltage (IEC 60255-5)
5 kV, 1.2/50 s, 0.5 J
9.2.3. Mechanical tests
Vibration IEC 60255-21-1, class I
Shock IEC 60255-21-2, class I
9.2.4. Environmental conditions
Operating temperature
-10 to +65 C
Transport and storage temperature
-40 to +70 C
Relative humidity < 75% (1 year, average value)
< 95% (no condensation permitted)
9.2.5. Casing
Degree of protection (IEC 60529) IP54
Dimensions (W x H x D) 130 x 170 x 210 mm
Material 1 mm steel plate
Weight 2.0 kg
Colour code RAL 7032 (Casing) / RAL 7035 (Back plate)
9.2.6. Package
Dimensions (W x H x D) 320 x 215 x 175 mm
Weight (Terminal, Package and Manual) 3.0 kg
