External analog inputs configuration (VAMPSET only)
Range Description
Communication read errors
Y2 Scaled value
X2 Modbus value
Point 2
Y1 Scaled value
X: -32000…32000
Y: -1000…1000
X1 Modbus value
Point 1
-32000…32000
Scaling
Off
set
Subtracted from Modbus
value, before running XY
scaling
InputR or HoldingR Modbus register type
1…9999
Modbus register for the
measurement
1…247 Modbus address of the I/O device
C, F, K, or V/A Unit selection
Active value
On / Off Enabling for measurement
