8. Connections
8.1. Rear panel view
1
2
3
4
5
6
7
8
9
10
11
1
2
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
20
8
7
6
5
4
3
2
1
X2
X1
X3
48...230V AC/DC
24VDC
Figure 8.1-1 Connections on the rear panel of the VAMP 50, VAMP 51 and
VAMP 52.
Terminal X1
No Symbol Description
1 IL1(S1) Phase current L1 (S1)
2 IL1(S1) Phase current L1 (S1)
3 IL2(S1) Phase current L2 (S1)
4 IL2(S1) Phase current L2 (S1)
5 IL3(S1) Phase current L3 (S1)
6 IL3(S1) Phase current L3 (S1)
7 Io1 Residual current Io1 common for 1 A and 5 A (S1)
8 Io1/5A Residual current Io1 5A (S2)
9 Io1/1A Residual current Io1 1A (S2)
10 Uo/U12/UL1 See chapter 4.7 (only VAMP52)
11 Uo/U12/UL1 See chapter 4.7 (only VAMP52)
1
2
3
4
5
6
7
8
9
10
11
