6.2 Communication protocols 6 Communication Technical description
182
VAMP 24h support phone +358 (0)20 753 3264 VM50.EN004
Configurable data model: selection of logical nodes
corresponding to active application functions
Configurable pre-defined data sets
Supported dynamic data sets created by clients
Supported reporting function with buffered and unbuffered
Report Control Blocks
Supported control model: direct with normal security
Supported horizontal communication with GOOSE:
configurable GOOSE publisher data sets, configurable
filters for GOOSE subscriber inputs, GOOSE inputs
available in the application logic matrix
Additional information can be obtained from the separate
documents “IEC 61850 conformance statement.pdf”, “IEC
61850 Protocol data.pdf” and “Configuration of IEC 61850
interface.pdf” on our website.
IEC 61850 main config parameters
Parameter Value Unit Description Set
Port 0 - 64000 IP protocol port Set
Check
upper
addresses
Yes / No
If the checkbox 'Check
upper addresses' is
checked the below
parameters are also
checked and used for
addressing when the
client is communicating
to the device, by default
this is disabled.
Set
.
The below parameters
are ACSE association
parameters described in
the standard part 61850-
8-1
AP ID nnn.nnn.nnn.nnn ACSE AP title value Set
AE
Qualifier
0 – 64000 ACSE AE qualifier
P Selector 0 – 4200000000 Presentation selector
S Selector 0 – 64000 Session selector
T Selector 0 – 64000 Transport selector
IED Name String
Identifcation of the
device. Each device must
have unique name.
Delete
dynamic
datasets
command
Send command to clear
all dynamic datasets
