SECTION 7: ILLUSTRATED PARTS LIST
7 - 2 090189-OP_r0 (JUNE-2022)
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
IMPORTANT
The above table listing contains items that require maintenance on a routine basis, and also those
parts that may require maintenance over the course of the
machine package's performance schedule.
Although this recommended list is pro-off ered as a comprehensive guide to replacement parts, dam-
age may occur to the machine beyond the scope of this listing.
Should any part of the
machine package that is not listed in Table 7A become damaged or inoperable,
contact the Vanair Service Department.
IMPORTANT
If additional spare parts are being stored for future use,
ensure that they are stored in proper containers that
allow for protection against contamination, and kept in a
clean area of moderate temperature reading. For infor-
mation on storing the machine package for periods of
non-use, consult Section 5.4.2, Long Term Storage.
TABLE 7A: RECOMMENDED SPARE PARTS LIST
KEY NO. DESCRIPTION ORDER NO. QTY
1 Belt, Drive 282389 3
2 Relay, 500A 280203 1
3 Fuse, 10A EL041538 1
4 Fuse, 5A EL270936 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
