SECTION 2:
SPECIFICATIONS
SECTION 2: SPECIFICATIONS
090189-OP_r0 (JUNE-2022) 2 - 1
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
2.1 GENERAL INTRODUCTION
The tables and fi gures in this section list the
specifi cations (including operational, output and
dimensional) of the overall machine. Contact the
Vanair
®
Service Department if additional specifi -
cations are needed that cannot be found in this
manual.
Refer to Figure 2-1 for general machine compo-
nent locations. For additional information, includ-
ing measurement specifi cations, refer to Figure
3-1 (machine and identifi cation and dimensions)
in Section 3, Installation.
TABLE 2A: SPECIFICATIONS FOR CAP•START HYDRAULIC MACHINE
GENERAL SYSTEM INFORMATION SPECIFICATION
HYDRAULIC MOTOR
Motor Speed: 2600 RPM
Motor GPM: 8 - 12 @ 3000 PSI
Pump Size Required: 8 - 25 GPM
Operating Temperature Limits: -40° - 140°F
TABLE 2B: CAPSCREW TIGHTENING TORQUE VALUES
SIZE GRADE LUBRICATED
1/4 - 20 UNC 5 6 ft-bs
5/16 - 18 UNC 5 13 ft-lbs
3/8 - 16 UNC 5 23 ft-lbs
1/2 - 13 UNC 5 55 ft-lbs
3/4 - 10 UNC 5 200 ft-lbs
