SECTION 7: ILLUSTRATED PARTS LIST
090189-OP_r0 (JUNE-2022) 7 - 21
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
8
8
8
9
10
11
9
12
13
14
15
7.9 DECAL IDENTIFICATION/LOCATION - 2 OF 2
WARNING
DO NOT REMOVE OR COVER ANY SAFE-
TY DECAL. Replace any safety decal that
becomes damaged or illegible.
6110154ID_r1_1of2
ITEM DESCRIPTION PART NUMBER QTY ITEM DESCRIPTION PART NUMBER QTY
8 LOGO, CAPSTART BY STARTALL 300 0 AMPS 12/24V 282481 3 12 DECAL, VANAIR SERIAL TAG 281373-002 1
9 LOGO, GOODALL WE START ENGINES 277884 3 13 DECAL, CASE DRAIN 5/8 X 1-3/4 276941 1
10 DECAL, WARN ELCTRICL SHOCK 2.0” TRIANGLE 281236 1 14 DECAL, LABEL HYDRAULIC RETURN 275972 1
11 DECAL, VA NAIR SERIAL TAG (MODEL/SERIAL # ONLY) 281373-001 1 15 DECAL, LABEL HYDRAULIC SUPPLY 275971 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
